IBA Dosimetry 엑스레이 필름 농도계 입니다.

IBA Dosimery의 모든 엑스레이 필름 Sensitometer(감광계)와 Densitometer(농도계) 제품은 IEC 61223-2-1, DIN 6868-2, DIN 6868-55의 규격을 만족하고 있습니다.

Sensitometers and Densitometers are developped according to IEC 61223-2-1, German Standards DIN 6868-2 (Constancy Tests) resp. DIN V 6868-55 (Acceptance Tests) and classified as Medical Devices according to EU Directive 93/42 (MDD)


IBA Densitometer



Densitometer Unilight D VD0204108
Suitable for constancy tests.
For a stepwise measurement of optical densities from a 21-step standard sensitometer wedge and for measurements of the optical density of X-rays (film size up to 35 x 35 cm).

Densitometer Unilight AD VD0204100
Suitable for acceptance and constancy tests.
Functionality as densitometer Unilight D, but including calculation of the processing parameters light sensitivity (LE) and light
contrast (LK).

Densitometer Unilight ADA VD0204102
Suitable for acceptance and constancy tests.
Functionality as densitometer Unilight D, but alternatively suitable for auto-reading of optical densities (motorized measuring section) and auto-calculating of light sensitivity (LE) and light contrast (LK). Incl. RS 232 interface.

Densitometer Unilight D / TR VD0204109
Suitable for constancy tests.
Functionality as densitometer Unilight D, but especially also suitable for dry laser films.

Densitometer Unilight D i VD0204111
Suitable for constancy tests.
Functionality as Densitometer Unilight D, but including RS 232 interface.

A Power Supply is necessary for all Types of Densitometers:
Power Supply VD0214260
For 110 V / 220 V DC

Optional Accessory:
Interface Cable VD0204112
For Densitometer Unilight D i

Densitometer Unilight D Technical Specifications and Data
Densitometer:
· Instrument is ready for use without warm-up time
· Power supply: accumulator 9 V with charger
· Own, extremely constant and spectrally adjusted light source
· Length of measuring arm 18 cm (e.g. for measurements in the centre of the film 35 x 35)
· Measuring diaphragm: 7 mm2 (according to DIN 6868/55)
· Measurement of density according to DIN 4512
· Measuring range:  0 < D < 4
· Measuring uncertainty at     D < 1: DD < + 0.02
                                         D > 1: DD < + 1.5 %
· Repetition accuracy of single measurement according to DIN: DD < + 0.02
· Zeroing and calibration is possible for the user by means of the enclosed calibration film
· Measuring results via LCD-display
· Different languages possible
· Temperature 15° C - 35° C
