옵션에 따라 X-ray, CT, MRI, Ultrasound 에서 사용할수 있게 선택하실 수 있습니다.

주문제작형 팬텀이기 때문에 원하는 장기나 진단, 질병, 특정 부위만을 제작할 수 있습니다.






“Adult Human Torso” is a lifelike anatomically correct phantom, from neck to pelvic area with all the organs present inside. This phantom can be specifically customized to be compatible with Ultrasound, MRI and/or CT imaging methods.
It is a perfect model for carrying out research and development projects.
This product has a wide variety of medical imaging applications. It can be customized to different pathologies as well as for specific training applications.
This product is available upon request. It can be modified to match your specific needs.

1.It can be customized to be compatible with Ultrasound, MR and CT.
2.Anatomically correct and realistic organs inside for carrying out research and development.
3.Rib cage and pelvic bones are available for X-Ray/Ultrasound/MRI imaging applications

What’s Inside the model:
1.Heart
2.Lungs
3.Liver
4.Stomach
5.Diaphragm
6.Spleen
7.Pancreas
8.Kidney
9.Vena cava
10.Esophagus tube
11.Aorta
12.Psoas Major
13.Colon
14.Bladder
15.Large intestine
16.Small intestine
17.Pelvic
18.Ribcage
19.Spine

(These organs can be added or removed to suit your application’s requirements)
Optional features (based upon request)
1.Internal hemorrhages at bilateral chambers, pelvic area, pericardial area, perisplenic areas etc.
2.Lesions and tumors at precise locations.
3.Customizing the phantom with motion or bleeding.

Materials used:
Soft tissue and organs: Composition of urethane base soft resin
Synthetic bones: Patented ceramic-reinforced epoxy-based composite material (optional)
Dimensions and Weight:
Size: 85 x 32 x 32 cm (approx.) Weight: 40 kgs (approx.)

Your order will Include:
1.Male Standard Torso
2.Design video
3.Manual
4.Hard carry case (optional)
